Mask Cutting Machine

  • XCLL4 25T 30T 250KN 300KN atom type travel head hydraulic mask pearl cotton die cutting press machine

    XCLL4 25T 30T 250KN 300KN atom type travel head hydraulic mask pearl cotton die cutting press machine

    The machine is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fiber, non-woven and other materials with shaped blade. 1. Adopting the structure of gantry framework, so the machine has high intensity and keep its shape. 2. The punch head can automatically move transversely, so visual field is perfect and the operation is safe. 3. Return stroke of the platen can be set arbitrarily to reduce idle stroke and improve efficiency. 4. Using ...
  • XCLL4 25T 30T 250KN 300KN atom type travel head hydraulic mask pearl cotton cutting press machine

    XCLL4 25T 30T 250KN 300KN atom type travel head hydraulic mask pearl cotton cutting press machine

    The machine is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fiber, non-woven and other materials with shaped blade. 1. Adopting the structure of gantry framework, so the machine has high intensity and keep its shape. 2. The punch head can automatically move transversely, so visual field is perfect and the operation is safe. 3. Return stroke of the platen can be set arbitrarily to reduce idle stroke and improve efficiency. 4. Using ...
  • HYL4 25T 30T 250KN 300KN atom type travel head hydraulic mask pearl cotton cutting press machine

    HYL4 25T 30T 250KN 300KN atom type travel head hydraulic mask pearl cotton cutting press machine

    The machine is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fiber, non-woven and other materials with shaped blade.

    1. Adopting the structure of gantry framework, so the machine has high intensity and keep its shape.

    2. The punch head can automatically move transversely, so visual field is perfect and the operation is safe.

    3. Return stroke of the platen can be set arbitrarily to reduce idle stroke and improve efficiency.

    4. Using differential oil way, cut is rapid and easy.

    Main Features:

      Pushbutton controls (time interlock synchronization during cutting phase) to ensure positive safety for the operator

      Really exceptional trolley displacement speed

      High power continuity

      Low energy consumption

      High reliability, no primary maintenance required

      On Demand



    HYL4-250

    HYL4-250A

    HYL4-350

    HYL4-350A

    HYL4-500

    HYL4-500A

    Working table size

    1600 mm

    1800 mm

    1800 mm

    2000 mm

    1800 mm

    2000 mm

    Travel head size

    500×500 mm

    650×650 mm

    650×650 mm

    760 x 760 mm

    650×650 mm

    760 x 760 mm

    Max cutting pressure

    25tons

    25tons

    35tons

    35tons

    50tons

    50tons

    stroke

    5-150 mm

    5-150 mm

    5-150 mm

    5-150 mm

    5-150 mm

    5-150 mm

    power

    2.2KW

    2.2KW

    3.0KW

    3.0KW

    4.0KW

    4.0KW

    speed

    1.07 m/sec

    1.07 m/sec

    1.07 m/sec

    1.07 m/sec

    1.07 m/sec

    1.07 m/sec

    Machine’s size

    2200 x720x2200 mm

    2400x720x205 0mm

    2500x900x2100 mm

    2700x900x2200 mm

    2500x900x2200 mm

    2700x900x2200 mm

    N.W

    1600 Kg

    2100Kg

    2600kg

    3000 Kg

    3800kg

    5000kg

  • 25T 30T precise four column automatic two-roller feeding travel head hydraulic mask textile cutting press machine

    25T 30T precise four column automatic two-roller feeding travel head hydraulic mask textile cutting press machine

    The machine is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fibre, non-woven and other materials with shaped blade. 1. The punch head can automatically move transversely, so the operation is laborsaving, the cutting force is strong. Because the machine is operated with both of hands, safety is high. 2. Use double cylinder and four-column oriented, automatically balancing links to ensure same cutting depth in every cutting region. 3...
  • XCLL3 precise four column automatic two-roller feeding travel head hydraulic mask textile cutting press machine

    XCLL3 precise four column automatic two-roller feeding travel head hydraulic mask textile cutting press machine

    The machine is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fibre, non-woven and other materials with shaped blade. 1. The punch head can automatically move transversely, so the operation is laborsaving, the cutting force is strong. Because the machine is operated with both of hands, safety is high. 2. Use double cylinder and four-column oriented, automatically balancing links to ensure same cutting depth in every cutting region. 3...
  • HYL4 precise four column automatic two-roller feeding travel head hydraulic mask textile cutting press machine

    HYL4 precise four column automatic two-roller feeding travel head hydraulic mask textile cutting press machine

    The machine is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fibre, non-woven and other materials with shaped blade. 1. The punch head can automatically move transversely, so the operation is laborsaving, the cutting force is strong. Because the machine is operated with both of hands, safety is high. 2. Use double cylinder and four-column oriented, automatically balancing links to ensure same cutting depth in every cutting region. 3...
  • 80T 100T 120T 800KN 1000KN 1200KN Traveling Head Hydraulic Press Automatic Facial Mask Cutting Press Mchine

    80T 100T 120T 800KN 1000KN 1200KN Traveling Head Hydraulic Press Automatic Facial Mask Cutting Press Mchine

    80T 100T 120T 800KN 1000KN 1200KN Traveling Head Hydraulic Press Automatic Facial Mask Cutting Press Mchine Uses and features:   1. The machine is applicable for large factories to use blade mould to do continuous and big quantity cutting for such non-metal materials as carpet, leather, rubber, fabric and so on. 2. PLC is equipped for conveyor system. Servo motor drives materials to come in from one side of the machine; after being cut the materials are delivered from the other side for...
